Dennis Javelin - Braking System



The braking system on the early Javelin was drum based all round and fitted with S-Cam style brakes.  We have designated these chassis as MK1’s.  Later Javelin’s had front disc brakes fitted with a D2 type caliper on the front and Z-Cam brakes fitted to the rear, these buses are designated as Mk2’s.  The most recent style of brakes are based on the D-Lisa type caliper and are designated as Mk3’s.  For ease of use we have created separate sections each different braking system. If you are unsure what system is fitted to your coach then please have your chassis no’ available when you are ordering parts.



To return to our home page click on one the buses above and they will take you there.



To go to another section click on the link below.



Front Axle Rear Axle Change Speed Cooling System Clutch & Flywheel Electrical System Engine Controls Engine and Mounting Exhaust System Fuel System & Gearbox

Hydraulic System Propshaft Steering & Wheels Suspension





S.Cam Front    S.Cam Rear    D2 Caliper    D-Lisa Caliper    Z.Cam





OE Part No   Our Part No   Part Description                                           Chassis     Price



415000       295555        Brake Chamber — Front

415001       295555        Brake Chamber — Front

415203       295555        Brake Chamber — Front

605208       274746        Stop Light Switch

605293       KW2966/1      Single Check Valve

609010       280375        Relay Valve

609011       274997        Quick Release Valve

610579       274423        Brake Chamber — Front                                      Mk1

610580       274423        Brake Chamber — Front

610582-A     295476        Low Pressure Switch

611463-6                   Brake Drum — Front                                         Mk1

611529       KY1916/1      Footbrake Valve Assembly

611529-1     295579        Footbrake Valve

611970       VPS48HI       Multi Circuit Protection Valve

612049       277148        Pressure Protection Valve

612503       KW2966/1      Single Check Valve

613553       KZ1291/2      Condensor

614170-1                   C Spring

650057       277486        D2 Governor Valve

650060       KX1058/1      Diff Protection Valve

650209       VPS48AI       Multi Circuit Protection Valve

650418-35                  Brake Camshaft Front — RH                                  Mk1

650418-36                  Brake Camshaft Front — LH                                  Mk1

650418-39                  Bush — Brake Camshaft                                      Mk1

650711-8                   Brake Drum — Rear                                          Mk1

651017-3                   O Ring — Brake Camshaft                                    Mk1

651166-8                   Pivot Pin                                                  Mk1

651166-9                   Anchor Pin — Brake Shoe                                    Mk1

651166-13                  O Ring Sleeve — Brake Camshaft                             Mk1

651166-14                  Roller — Brake Camshaft                                    Mk1

651166-15                  Roller Pin — Brake Camshaft                                Mk1

651370-1                   Brake Camshaft Rear — RH                                   Mk1

651371-1                   Brake Camshaft Rear — LH                                   Mk1

651623                     Slack Adjuster — Front                                     Mk1           85.00

651777                     Slack Adjuster — Rear                                      Mk1           85.00

651847        4613240080   Footbrake Valve Assembly

651847-1      4613245200   Footbrake Valve

651929-2                   Brake Shoe Return Spring                                   Mk1

652405        KY2498/1     Hand Control Valve                                         Mk1&2        115.00

652406        K2B0528      Spring Brake — Type 24/80

652439        KZ1143/3     Compressor                                                 Mk1

652568                     Slack Adjuster — Rear 8.5m Chassis                         Mk1           85.00

652283        269827       Air Dryer — AD2                                            Mk1

653188                     Brake Drum — Rear

653404                     Brake Shoe Front — Lined (exchange unit)                   Mk1

653563-7                   Brake Pad — Axle Set                                       Mk2           55.00

653563-9                   Guide Pin Kit                                              Mk2

653564                     Brake Caliper — RH (exchange unit)                         Mk2          585.00

653565                     Brake Disc                                                 Mk2           85.00

653613                     Compressor — Reed Valve                                    All

653613-1                   Cylinder Head Kit — Compressor                             All

653613-3                   Valve Plate Kit — Compressor                               All

653747-1                   Brake Shoe Rear — Lined (exchange unit)                    Mk1

653802       1188782-01    Brake Chamber — Front

653865       LA8223        Air Dryer                                                  Mk1&2        210.00

653877-1     BR9152        ABS Modulator

653877-6     AE4105        Double Check Valve

653877-8                   ABS Sensor Cable                                                         24.00

653885       AC574         Relay Valve

654082-4                   Brake Drum — Rear

654084-4                   Brake Shoe — Leading — Lined (exchange unit)

654084-5                   Brake Shoe — Trailing — Lined (exchange unit)

654084-1                   Dustshield Rear                                            Mk2           35.00

654084-2                   Camshaft — LH                                              Mk2&3

654085-1                   Camshaft — RH                                              Mk2&3

654466        K2B0521      Spring Brake — Type 30-98

654598        K2B0506      Spring Brake — Type 24/80

654733        KW4455/1     Single Check Valve

654734        295358       Double Check Valve

655201        VPS48HI      Multi Circuit Protection Valve

655377-1      1047         Brake Pads — Axle Set                                      Mk3

655711        DR4125       Charging Valve

655750                     Brake Disc                                                 Mk3           80.00

656249        9347141250   Multi Circuit Protection Valve

656564-5      BCP105       Brake Lever                                                Mk3           25.00

656564-6      BCP373       Brake Lever                                                Mk3           25.00

656882        LA8226       Air Dryer                                                               190.00

657493        DPM92        Hand Control Valve (phone for alternatives)                              65.00

658058-3      VL89         Brake Shoe Axle Set — Lined (exchange unit)                Mk2&3        140.00

658209        LA8226       Air Dryer                                                               195.00

659044        LP4858       Compressor — Euro 3

659372        AC574        Relay Valve                                                              35.00
