Dennis Dart  -  Suspension



The Dart has two different suspension systems depending on the chassis configuration.  The original system was leaf spring and this was used on all chassis no’s which contain the letters SDL in the chassis code. The later system is an air based system and is fitted to chassis that are more commonly know as Super Low Floor (SLF) buses.  These buses commonly have the prefix SFD.   Please note however that some early SFD prefixed chassis were built to an SDL standard. In order to ensure that we supply you with the correct parts please assist us by having your chassis no available when ordering any parts.  Please note that all parts marked * are exchange units.



To go to another section click on the link below.



Front Axle Rear Axle Braking Change Speed Cooling Electrical Engine Controls



Engine Parts Hoses Exhaust Fuel System Gearbox Hydraulics Propshaft Steering



To return to our home page click on one of the buses above and they will take you there.



OE Part No            Our Part No   Part Description                             Chassis       Price



264184                BCP308        Bush — Road Spring — Front                     SLF         22.00

408440-7           BCP253           Bolt — Front Suspension                        SLF         7.00

408447-8                            Bolt — Front Suspension                        SLF         5.00

409768             BCP229           Road Spring — Rear                             Mk1&2       180.00

410847             BCP187           Road Spring — Front                            Mk1&2       165.00

412343                HBU3164       Bump Stop                                      Mk1&2       20.00

410912                              U Bolt — Rear                                  Mk1&2       20.00

415123                              Road Spring — Front                            Mk1&2

417257                HBU3164       Bump Stop                                      SLF         20.00

417947             BCP096           Bush — Road Spring — Rear                      SLF         25.00

417948                            Panhard Rod                                    SLF         240.00

419364             BCP542           Road Spring — Rear                             SLF         240.00

419385             BCP116           U Bolt — Rear                                  SLF         30.00

419392             BCP541           Road Spring — Front                            SLF         105.00

432270             BCP758        Panhard Beam                                   SLF         380.00

609355                454ATF        Solenoid Valve                                 SLF         45.00

611910-2              HBU2890       Bush — Rear Spring                             Mk1&2       10.00

651647                HBU3164       Bump Stop                                      Mk1         22.00

651509                SV1351        Levelling Valve                                SLF         95.00

652582                SV1294        Levelling Valve                                SLF         105.00

652851-2              HBU2889       Bush — Front Spring                            Mk1&2       10.00

653517             BC65-0775        Shock Absorber                                 Mk1&2       33.00

653518             BC65-0775        Shock Absorber                                 Mk1&2       33.00

653826                DB2116        Pressure Proportioning Valve                   Mk1&2

654042                              Bush — Anti Roll Bar                           Mk1&2       14.00

654201                B4300         Pilot Valve                                    SLF         34.00

656165                               Bump Stop                                      SLF         12.00

655687                4640060020    Levelling Valve                                SLF         65.00

655606-1           9921             Air Spring Diaphragm                           SLF         32.00

655606-2           BCP372           Air Bag Clamp Plate                            SLF         30.00

655606-3           PO24             Air Bag Piston                                 SLF         65.00

655730                              Shock Absorber                                 Mk2         33.00

655731                              Shock Absorber                                 Mk2         33.00

657505                              Proximity Switch Assembly                      SLF         55.00

657866                              Shock Absorber                                 SLF         33.00

657867                           Shock Absorber                                 SLF         33.00

658105             10MCB120/160  Bolt — Front Suspension                        SLF          6.00

659900                           Shock Absorber                                 SLF         33.00
