Dennis Dart — Braking System.



The braking system on the Dart changes according to chassis no.  We have designated chassis’s up to 1992 as Mk1’s, from 1992 to 1996/7 are Mk2 and thereafter they are known as super low floor (SLF) and/or super pointer dart (SPD).  In order to ensure that we supply you with the correct parts please assist us by having your chassis no available when ordering any parts.  Please note that all parts marked * are exchange units.



To go to another section click on the link below.



Front Axle Rear Axle Change Speed Cooling Electrical Engine Controls Engine Parts Hoses



Exhaust Fuel system Gearbox Hydraulics Propshaft Steering Suspension



To return to our home page click on one of the buses above and they will take you there.









Tel:(0044)141 9527947  Fax:(0044)141 2373272      Email:sales@busandcoachparts.co.uk

Bus and Coach Parts Ltd

11 South Douglas St,

Clydebank,

G81 1PD

OE Part No   Our Part No   Part Description                                           Chassis     Price



420496                     Air Dryer Coil Pipe

427364-1     BC427364-1    Brake Hose                                                  SLF         13.00

605208       274746        Stop Light Switch                                           All         14.00

608238-18    BC608238-18   Brake Hose                                                  Mk1          6.50

609011       274997        Quick Release Valve                                         Mk1         13.00

610153       BCP590        Air Reservoir                                               Mk1         90.00

610582A      1185782       Low Pressure Switch                                         Mk1         14.00

611529       KY1916/1      Footbrake Valve Assembly*                                   Mk1        175.00

611740       KY890/1       Load Sensing Valve*                                         Mk 1&2     230.00

611970       VPS48HI       Four Circuit Protection Valve*                              MK1

613553       KX2073/7      Pressure Relief Valve                                       Mk1

614922       VPS48H        Four Circuit Protection Valve*                              Mk2

614927       KX1294/1      Quick Release Valve                                         Mk2/SLF     14.00

650062       BCP592        Air Reservoir                                               Mk1         95.00

650209       VPS48AI       Four Circuit Protection Valve                               Mk1

652405       KY2498/1      Hand Control Valve*                                         Mk1         90.00

652439       KZ1143/3      Compressor*                                                 Mk1

652600-6                   Retarder Pressure Switch — 7psi                             All         15.00

652800-26    BC652800-26   Brake Drum — Rear                                           All         65.00

652841-25    BC652841-25   Brake Drum — Front                                          All         85.00

652881       1186733-01    Brake Chamber*                                              Mk1         75.00

652882       K2E4001       Spring Brake*                                               Mk1        125.00

652882-1     K2E0311       Spring Brake Portion*                                       Mk1        106.00

652883                     Brake Chamber*                                              Mk1         75.00

652885       LA8223        Air Dryer                                                   Mk1        210.00

653251-1     FI/124        Brake Shoe — Lined                                          Mk1         45.00

653251-1XX   FI/124X       Brake Shoe — Lined* (see note below)                        Mk1         20.00

653251-2     FI/124(UL)    Brake Shoe — Unlined                                        Mk1         30.00

653251-5                   Brake Release Spring                                        All          3.50

653251-6                   Brake Release Spring                                        All          3.50

653251-7                   Brake Pressure Spring                                       Mk1          3.00

653251-8                   Brake Retainer Spring                                       Mk1          0.50

653251-9                   Brake Expander                                              Mk1        225.00

653251-13                  Brake Expander Repair Kit                                   Mk1         65.00

653152-14                  Brake Expander Repair Kit                                   Mk1        120.00

653251-16                  Brake Expander Repair Kit                                   Mk1         15.00

653251-18                  Brake Expander Adjuster Washer                              Mk1          0.50

653251-19                  Brake Expander Adjuster Screw                               Mk1         12.50

653251-20                  Brake Expander Shoe Locator                                 Mk1          7.25

653251-21                  Brake Expander Spring Seal                                  Mk1          1.50

653251-22                  Brake Expander Screw                                        Mk1          2.00

653613       1194215       Compressor*                                                 Mk2/SLF    410.00

653613-1     1189308       Compressor Head Kit*                                        Mk2/SLF    130.00

653826       DB2116        Pressure Proportioning Valve                                Mk 1&2

653865       LA8223        Air Dryer                                                   Mk2        210.00

653885       AC574         Relay Valve                                                 Mk1&2       45.00

654079-3                   Retarder Pressure Switch — 3psi                             All         15.00

654160-6                   Retarder Pressure Switch — 15psi                            All         15.00

654280       1186733-01    Brake Chamber*                                              Mk1         75.00

654281       1186733-01    Brake Chamber*                                              Mk1         75.00

654729       LA8227        Air Dryer                                                   Mk2        195.00

654732       DPM94         Hand Control Valve                                          Mk2/SLF     65.00

654755       LA8226        Air Dryer                                                   Mk2        195.00

654756       KY1916/3      Footbrake Valve Assembly*                                   Mk2/SLF    210.00

654757       KX1294/1      Quick Release Valve                                         Mk2/SLF     18.00

654758       1189702-01    Brake Chamber*                                              Mk2         75.00

654759       K2E4002       Spring Brake*                                               Mk2        165.00

654759-1     K2E0301       Spring Brake Portion*                                       Mk2        106.00

654804                     Hose — Compressor Pipe                                      Mk2/SLF     28.00

654812-1     BCP068        Brake Dustshield                                            Mk2/SLF     45.00

654812-5                   Brake Shoe Leaf Spring                                      Mk2/SLF      1.75

654812-9     PB22(UL)      Brake Shoe — Unlined                                        Mk2/SLF     17.00

654812-13                  Brake Expander                                              Mk2/SLF    225.50

654812-15                  Brake Expander Repair Kit                                   Mk2/SLF    120.00

654812-16                  Brake Expander Repair Kit                                   Mk2/SLF     60.00

654812-17                  Brake Expander Repair Kit                                   Mk2/SLF     50.00

654812-18                  Brake Expander Repair Kit                                   Mk2/SLF     17.00

654867       VPS45C        Four Circuit Protection Valve                               Mk2

654975-1     PB22          Brake Shoe — Lined                                          Mk2/SLF     40.00

654975-1XX   PB22X         Brake Shoe — Lined* (see note below)                        Mk2/SLF     20.00

654979-1                   Air Reservoir                                                            Mk2/SLF     60.00

654979-2                   Air Reservoir                                               All         65.00

654979-9                   Air Reservoir                                               All         70.00

654979-10                  Air Reservoir                                               All         75.00

655142       K2E4002       Spring Brake*                                               Mk2        125.00

655142-1     K2E0301       Spring Brake Portion*                                       Mk2        106.00

655408-1                   Retarder Pressure Switch — 60psi                            All         15.00

655610       AE4158        Four Circuit Protection Valve                               Mk2

655611       BR5530        Load Sensing Valve*                                         SLF

655776       4334010030    Solenoid Valve

655834       EF90YE        Brake Chamber*                                              Mk2         70.00

656249       9347141250    Four Circuit Protection Valve                               SLF        140.00

656295       K2E4002       Spring Brake*                                               Mk2        125.00

656295-1     K2E0301       Spring Brake Portion*                                       Mk2        106.00

656296       K2E4002       Brake Chamber*                                              Mk2        125.00

656296-1     K2E0301       Brake Chamber Portion*                                      Mk2        106.00

656324       DPM92         Hand Control Valve*                                         Mk2/SLF     95.00

656375                     Brake Hose                                                  SLF         15.00

656759       EF90YES       Brake Chamber*                                              SLF         70.00

656882       LA8226        Air Dryer                                                   Mk2        195.00

657033       1194215       Compressor*                                                 Mk2/SLF    410.00

657262       KY1916/3      Footbrake Valve Assembly*                                   Mk2/SLF    210.00

657344       K2E4035       Brake Chamber*                                              SPD        140.00

657344-1     K2E0304       Brake Chamber Portion*                                      SLF/SPD    106.00

657345       K2E4036       Brake Chamber*                                              SLF        143.00

657345-1     K2E0304       Brake Chamber Portion*                                      SLF        106.00

657346       EF120YES      Brake Chamber*                                              SLF         70.00

657493       DPM92         Hand Control Valve*                                         SLF         95.00

657993                     Brake Chamber*                                              SLF        140.00

657993-1                   Brake Chamber Portion*                                      SLF        115.00

658257       KX1729/3      Pressure Relief Valve                                       Mk2

658414       1194454       Compressor *

658499                     Brake Chamber*                                              SPD        POA

659044       LP4858        Compressor*
